Establishment and application of an indirect ELISA method for detecting antibodies against fowlpox virus ORF127 protein

doi:10.3969/j.issn.1004-1524.20250139

Acta Agriculturae Zhejiangensis ›› 2025, Vol. 37 ›› Issue (10): 2057-2065.DOI: 10.3969/j.issn.1004-1524.20250139

• Animal Science • Previous Articles Next Articles

Establishment and application of an indirect ELISA method for detecting antibodies against fowlpox virus ORF127 protein

HUA Jionggang¹(), ZHU Yinchu¹, YE Jialin², ZHANG Cun¹, CHEN Liu¹, NI Zheng¹, FU Yuan¹, HUO Suxin¹, YUN Tao¹^,^*()

1. Zhejiang Key Laboratory of Livestock and Poultry Biotech Breeding, Key Laboratory of Livestock and Poultry Resources (Poultry) Evaluation and Utilization, Ministry of Agriculture and Rural Affairs, Zhejiang Engineering Research Center for Poultry Breeding Industry and Green Farming Technology, Institute of Animal Husbandry and Veterinary Sciences, Zhejiang Academy of Agricultural Sciences, Hangzhou 310021, China
2. International Division, Hangzhou High School, Hangzhou 310020, China

Received:2025-02-24 Online:2025-10-25 Published:2025-11-13

Abstract

Abstract:

To establish a rapid and accurate method for detecting fowlpox virus (FPV) antibodies, this study cloned the antigenic epitope region of FPV ORF127 gene into the pET-28a(+) prokaryotic expression vector. The truncated FPV ORF127 protein was successfully expressed and purified. Using this recombinant protein as a coating antigen, an indirect ELISA was developed through systematic optimization of reaction parameters. The method was comprehensively validated, including specificity, sensitivity, repeatability tests, and clinical serum sample detection. The results showed that the optimal reaction conditions for the indirect ELISA were as follows: coating antigen concentration of 10 μg·mL^-1, serum dilution of 1∶100, and enzyme-labeled secondary antibody dilution of 1∶25 000. Specificity tests revealed that except for FPV-positive serum, no cross-reactions were observed with positive sera against six other viruses (Newcastle disease virus, H9 subtype avian influenza virus, infectious bursal disease virus, infectious laryngotracheitis virus, fowl adenovirus type 4, and turkey herpesvirus). Sensitivity tests showed that FPV-positive serum remained detectable at a dilution of 1∶800. Reproducibility tests demonstrated that the intra-assay and inter-assay coefficients of variation were 1.81%-7.07% and 2.12%-7.16%, respectively, both below 10%. Clinical serum sample testing showed a total positivity rate of 79.4% (143/180) among 180 samples. These results indicate that the established indirect ELISA method exhibits high specificity, sensitivity, reproducibility, and stability. It can provides a reliable tool for detecting FPV antibodies in vaccinated flocks and supporting FPV epidemiological investigations.

Key words: fowlpox virus, ORF127 protein, indirect ELISA, antibody

CLC Number:

S852.657

HUA Jionggang, ZHU Yinchu, YE Jialin, ZHANG Cun, CHEN Liu, NI Zheng, FU Yuan, HUO Suxin, YUN Tao. Establishment and application of an indirect ELISA method for detecting antibodies against fowlpox virus ORF127 protein[J]. Acta Agriculturae Zhejiangensis, 2025, 37(10): 2057-2065.

Figures/Tables 8

References 23

[1]	BERTELLONI F, CECCHERELLI R, MARZONI M, et al. Molecular detection of Avipox virus in wild birds in central Italy[J]. Animals, 2022, 12(3): 338.
[2]	MATOS M, BILIC I, PALMIERI N, et al. Epidemic of cutaneous fowlpox in a naïve population of chickens and turkeys in Austria: detailed phylogenetic analysis indicates co-evolution of fowlpox virus with reticuloendotheliosis virus[J]. Transboundary and Emerging Diseases, 2022, 69(5): 2913-2923.
[3]	姜绍全, 王金亮, 秦燕. 海兰褐蛋鸡痘病毒的分离与鉴定[J]. 山东畜牧兽医, 2015, 36(1): 36-37.
	JIANG S Q, WANG J L, QIN Y. Isolation and identification of poxvirus from hailan brown laying hens[J]. Shandong Journal of Animal Science and Veterinary Medicine, 2015, 36(1): 36-37. (in Chinese)
[4]	KIM T J, SCHNITZLEIN W M, MCALOOSE D, et al. Characterization of an avianpox virus isolated from an Andean condor (Vultur gryphus)[J]. Veterinary Microbiology, 2003, 96(3): 237-246.
[5]	YEHIA N, ELSAYED S, AL-SAEED F A, et al. Current situation and genomic characterization of fowlpox virus in lower Egypt during 2022[J]. Poultry Science, 2023, 102(8): 102769.
[6]	AFONSO C L, TULMAN E R, LU Z, et al. The genome of fowlpox virus[J]. Journal of Virology, 2000, 74(8): 3815-3831.
[7]	WELI S C, TRYLAND M. Avipoxviruses: infection biology and their use as vaccine vectors[J]. Virology Journal, 2011, 8: 49.
[8]	赵宏吉, 张金花, 司朵朵, 等. 山羊痘病毒G9蛋白的原核表达及间接ELISA方法的建立[J]. 中国预防兽医学报, 2021, 43(3): 280-284.
	ZHAO H J, ZHANG J H, SI D D, et al. Prokaryotic expression of G9 protein of GTPV and establishment of an indirect ELISA[J]. Chinese Journal of Preventive Veterinary Medicine, 2021, 43(3): 280-284. (in Chinese with English abstract)
[9]	叶伟成, 云涛, 朱寅初, 等. 基于番鸭细小病毒VP3蛋白的间接ELISA方法建立[J]. 浙江农业科学, 2022, 63(11): 2740-2745, 2750.
	YE W C, YUN T, ZHU Y C, et al. Establishment of indirect ELISA assay based on VP3 protein of Muscovy duck parvovirus[J]. Journal of Zhejiang Agricultural Sciences, 2022, 63(11): 2740-2745, 2750. (in Chinese with English abstract)
[10]	OJEDA S, DOMI A, MOSS B. Vaccinia virus G9 protein is an essential component of the poxvirus entry-fusion complex[J]. Journal of Virology, 2006, 80(19): 9822-9830.
[11]	GRAY R D M, ALBRECHT D, BEERLI C, et al. Nanoscale polarization of the entry fusion complex of vaccinia virus drives efficient fusion[J]. Nature Microbiology, 2019, 4(10): 1636-1644.
[12]	FOO C H, WHITBECK J C, PONCE-DE-LEÓN M, et al. The myristate moiety and amino terminus of vaccinia virus l1 constitute a bipartite functional region needed for entry[J]. Journal of Virology, 2012, 86(10): 5437-5451.
[13]	SHINODA K, WYATT L S, MOSS B. The neutralizing antibody response to the vaccinia virus A28 protein is specifically enhanced by its association with the H2 protein[J]. Virology, 2010, 405(1): 41-49.
[14]	ADEBAJO M C, ADEMOLA S I, OLUWASEUN A. Seroprevalence of fowl pox antibody in indigenous chickens in jos north and south council areas of Plateau state, Nigeria: implication for vector vaccine[J]. International Scholarly Research Notices, 2012, 2012(1): 154971.
[15]	MOCKETT A P A, SOUTHEE D J, TOMLEY F M, et al. Fowlpox virus: its structural proteins and immunogens and the detection of viral-specific antibodies by ELISA[J]. Avian Pathology, 1987, 16(3): 493-504.
[16]	雪鹏, 刘悦竹, 姜世金, 等. 用间接ELISA检测鸡痘病毒抗体的建立与应用[J]. 中国兽医杂志, 2005, 41(6): 15-16.
	WANG X P, LIU Y Z, JIANG S J, et al. Establishment and application of an indirect ELISA to detect antibodies against poultry pox[J]. Chinese Journal of Veterinary Medicine, 2005, 41(6): 15-16. (in Chinese)
[17]	张体银, 孙蕾, 孙学辉, 等. 应用间接ELISA检测鸡痘病毒抗体方法的建立[J]. 中国预防兽医学报, 2005, 27(6): 540-543.
	ZHANG T Y, SUN L, SUN X H, et al. Development of indirect ELISA for detection of antibodies against fowlpox virus[J]. Chinese Journal of Preventive Veterinary Medicine, 2005, 27(6): 540-543. (in Chinese with English abstract)
[18]	纪朋艳, 卢广林. 检测鸡痘病毒抗体间接ELISA方法的建立[J]. 黑龙江畜牧兽医, 2012(23): 94-95.
	JI P Y, LU G L. Establishment of indirect ELISA for detection of fowlpox virus antibody[J]. Heilongjiang Animal Science and Veterinary Medicine, 2012(23): 94-95. (in Chinese)
[19]	张琪, 庞文静, 付明哲, 等. 山羊痘病毒ORF103蛋白的原核表达及间接ELISA抗体检测方法的建立与应用[J]. 中国兽医科学, 2017, 47(5): 537-543.
	ZHANG Q, PANG W J, FU M Z, et al. Prokaryotic expression of ORF103 protein of capripox virus and establishment of indirect ELISA for the detection of antibodies against the virus[J]. Chinese Veterinary Science, 2017, 47(5): 537-543. (in Chinese with English abstract)
[20]	VENKATESAN G, KUMAR TELI M, SANKAR M, et al. Expression and evaluation of recombinant P32 protein based ELISA for sero-diagnostic potential of capripox in sheep and goats[J]. Molecular and Cellular Probes, 2018, 37: 48-54.
[21]	DASHPRAKASH M, VENKATESAN G, KUMAR A, et al. Prokaryotic expression, purification and evaluation of goatpox virus ORF117 protein as a diagnostic antigen in indirect ELISA to detect goatpox[J]. Archives of Virology, 2019, 164(4): 1049-1058.
[22]	邓舜洲, 蒋新华, 冷闯, 等. 猪痘病毒P35基因的原核表达及间接ELISA抗体检测方法的建立[J]. 中国兽医学报, 2013, 33(10): 1488-1492.
	DENG S Z, JIANG X H, LENG C, et al. Establishment of an indirect ELISA for detection of antibodies against swinepox virus with the recombinant P35 as the coating antigen[J]. Chinese Journal of Veterinary Science, 2013, 33(10): 1488-1492. (in Chinese with English abstract)
[23]	朱俊达, 王爽, 任书凝, 等. 基于猴痘病毒A27L蛋白的间接ELISA抗体检测方法的建立[J]. 中国兽医杂志, 2022, 58(10): 1-7.
	ZHU J D, WANG S, REN S N, et al. Establishment of indirect ELISA method for detection of monkeypox virus antibody based on A27L protein[J]. Chinese Journal of Veterinary Medicine, 2022, 58(10): 1-7. (in Chinese with English abstract)

血清稀释度 Serum dilution	项目 Item	不同FPV-127抗原质量浓度的吸光度Absorbance of FPV-127 antigens with different mass concentration
血清稀释度 Serum dilution	项目 Item	20 μg·mL^-1	10 μg·mL^-1	5 μg·mL^-1	2.5 μg·mL^-1	1.25 μg·mL^-1	0.625 μg·mL^-1
1∶25	P	2.220	2.003	1.590	1.138	0.793	0.671
	N	0.673	0.403	0.243	0.167	0.129	0.210
	P/N	3.299	4.970	6.543	6.814	6.117	3.195
1∶50	P	2.146	1.799	1.130	0.753	0.486	0.404
	N	0.389	0.243	0.145	0.101	0.088	0.086
	P/N	5.517	7.403	7.793	7.485	5.523	4.698
1∶100	P	2.117	1.474	0.896	0.497	0.291	0.252
	N	0.257	0.148	0.096	0.074	0.062	0.066
	P/N	8.237	9.959	9.333	6.716	4.694	3.818
1∶200	P	1.896	1.145	0.562	0.311	0.189	0.149
	N	0.215	0.123	0.099	0.065	0.067	0.054
	P/N	8.817	9.309	5.677	4.785	2.821	2.759

血清稀释度 Serum dilution	项目 Item	不同FPV-127抗原质量浓度的吸光度Absorbance of FPV-127 antigens with different mass concentration
血清稀释度 Serum dilution	项目 Item	20 μg·mL^-1	10 μg·mL^-1	5 μg·mL^-1	2.5 μg·mL^-1	1.25 μg·mL^-1	0.625 μg·mL^-1
1∶25	P	2.220	2.003	1.590	1.138	0.793	0.671
	N	0.673	0.403	0.243	0.167	0.129	0.210
	P/N	3.299	4.970	6.543	6.814	6.117	3.195
1∶50	P	2.146	1.799	1.130	0.753	0.486	0.404
	N	0.389	0.243	0.145	0.101	0.088	0.086
	P/N	5.517	7.403	7.793	7.485	5.523	4.698
1∶100	P	2.117	1.474	0.896	0.497	0.291	0.252
	N	0.257	0.148	0.096	0.074	0.062	0.066
	P/N	8.237	9.959	9.333	6.716	4.694	3.818
1∶200	P	1.896	1.145	0.562	0.311	0.189	0.149
	N	0.215	0.123	0.099	0.065	0.067	0.054
	P/N	8.817	9.309	5.677	4.785	2.821	2.759

项目 Item	不同酶标二抗稀释度的吸光度Absorbance with different dilutions of enzyme-labeled second antibody
项目 Item	1∶10 000	1∶15 000	1∶20 000	1∶25 000	1∶30 000	1∶35 000
P	2.227	2.073	1.833	1.693	1.540	1.352
N	0.207	0.133	0.110	0.108	0.103	0.101
P/N	10.758	15.586	16.664	15.676	14.951	13.386

项目 Item	不同酶标二抗稀释度的吸光度Absorbance with different dilutions of enzyme-labeled second antibody
项目 Item	1∶10 000	1∶15 000	1∶20 000	1∶25 000	1∶30 000	1∶35 000
P	2.227	2.073	1.833	1.693	1.540	1.352
N	0.207	0.133	0.110	0.108	0.103	0.101
P/N	10.758	15.586	16.664	15.676	14.951	13.386

血清 Serum	稀释倍数 Dilution ratio	D₄₅₀ D₄₅₀
阳性血清Positive serum	100	1.394
	200	0.988
	400	0.652
	800	0.403
	1 600	0.259
	3 200	0.165
	6 400	0.117
阴性血清Negative serum	100	0.123

Establishment and application of an indirect ELISA method for detecting antibodies against fowlpox virus ORF127 protein

RichHTML

PDF (PC)

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 8

References 23

Related Articles 15

Recommended Articles

Metrics

Comments

血清编号 Serum number	批内重复试验Intra batch repeated experiment			批间重复试验Inter batch repeated experiment
血清编号 Serum number	D₄₅₀平均值 Average of D₄₅₀ value	标准差 Standard deviation	变异系数 Coefficient of variation/%	D₄₅₀平均值 Average of D₄₅₀ value	标准差 Standard deviation	变异系数 Coefficient of variation/%
1	1.448	0.029	2.00	1.410	0.041	2.91
2	1.161	0.021	1.81	1.132	0.024	2.12
3	0.779	0.015	1.93	0.768	0.022	2.86
4	0.615	0.019	3.08	0.628	0.045	7.16
5	0.388	0.012	3.09	0.376	0.015	3.99
6	0.341	0.014	4.09	0.352	0.012	3.41
7	0.163	0.009	5.52	0.162	0.010	6.17
8	0.113	0.008	7.07	0.110	0.004	3.63
