Effect of spatial heterogeneity of solar greenhouse environment on the growth performance of tomato seedlings

doi:10.3969/j.issn.1004-1524.20250544

Acta Agriculturae Zhejiangensis ›› 2026, Vol. 38 ›› Issue (7): 1345-1354.DOI: 10.3969/j.issn.1004-1524.20250544

• Horticultural Science • Previous Articles Next Articles

Effect of spatial heterogeneity of solar greenhouse environment on the growth performance of tomato seedlings

ZHANG Xiaoping¹(), SHEN Hui¹^,²^,³^,⁴^,^*(), ZHANG Jie¹

¹ College of Civil Engineering and Water Conservancy Engineering, Ningxia University, Yinchuan 750021, China
² Ningxia Water-Saving Irrigation and Water Resources Regulation Engineering Technology Research Center, Yinchuan 750021, China
³ Engineering Research Center for Efficient Utilization of Modern Agricultural Water Resources in Arid Areas of Ministry of Education, Yinchuan 750021, China
⁴ Ningxia Key Laboratory of Digital Water Governance and Yellow River Water Network, Yinchuan 750021, China

Received:2025-08-18 Online:2026-07-25 Published:2026-08-20

Abstract

Abstract:

To investigate the effects of different planting positions in solar greenhouses on the greenhouse environment and the growth of tomato seedlings in arid areas, the tomato cultivar Fenguan 503 was used as the experimental material. A seedling cultivation experiment was conducted at different planting positions in a film-covered semi-arched solar greenhouse oriented east-west in length and north-south in width. Environmental factors inside the greenhouse were monitored using sensors, the variation characteristics of the greenhouse environment were analyzed, the physiological and growth traits of tomato seedlings were measured, and the membership function method was employed to comprehensively evaluate seedling performance at different planting positions. The results showed that temperature and humidity were higher in the central area than in the surrounding areas. Illuminance exhibited a spatial pattern of east > west and south > north. Along the longitudinal direction, substrate temperature in the central area was higher than that on the eastern and western sides, whereas along the transverse direction, substrate temperature was higher in the north than in the south. The western area favored seed germination, seedling growth, and organic matter accumulation, the northern area promoted organic matter accumulation and root development, and the eastern area tended to enhance root growth while suppressing aboveground growth. Comprehensive evaluation of growth traits of tomato seedlings based on the membership function method indicated that seedlings in the northern area achieved the highest score (0.845).

Key words: solar greenhouse, tomato seedling, membership function method, planting position, environmental change

CLC Number:

S641.2

ZHANG Xiaoping, SHEN Hui, ZHANG Jie. Effect of spatial heterogeneity of solar greenhouse environment on the growth performance of tomato seedlings[J]. Acta Agriculturae Zhejiangensis, 2026, 38(7): 1345-1354.

Figures/Tables 9

References 31

[1]	王惠, 孙园朝, 刘天翔, 等. 西北地区不同园艺设施类型的发展现状与趋势[J]. 北方园艺, 2024(17): 137-143.
	Wang H, Sun Y Z, Liu T X, et al. Development status and trend of different types of horticultural facilities in northwest China[J]. Northern Horticulture, 2024(17): 137-143.
[2]	丁亚会, 张云鹤, 孙宁, 等. 我国设施农业发展的国际经验与启示[J]. 江苏农业科学, 2023, 51(16): 1-8.
	Ding Y H, Zhang Y H, Sun N, et al. International experience and enlightenment on development of China’s facility agriculture[J]. Jiangsu Agricultural Sciences, 2023, 51(16): 1-8.
[3]	杨冬艳, 王丹, 桑婷, 等. 日光温室东西垄向栽培小型西瓜品种适应性评价[J]. 中国蔬菜, 2025(5): 97-105.
	Yang D Y, Wang D, Sang T, et al. Adaptability evaluation of small-fruited watermelon varieties cultivated in east west ridge direction in solar greenhouses[J]. China Vegetables, 2025(5): 97-105.
[4]	陈思宁, 赵艳霞, 任义方, 等. 基于日光温室黄瓜低温冷害风险的天气指数保险设计[J]. 中国农业气象, 2025, 46(1): 14-22.
	Chen S N, Zhao Y X, Ren Y F, et al. Weather index insurance design based on low temperature disaster risk of cucumber in solar greenhouse[J]. Chinese Journal of Agrometeorology, 2025, 46(1): 14-22.
[5]	武荣盛, 吴瑞芬, 金林雪, 等. 内蒙古自治区日光温室气候适宜性区划[J]. 应用生态学报, 2023, 34(5): 1305-1312.
	Wu R S, Wu R F, Jin L X, et al. Climate suitability division of solar greenhouse in Inner Mongolia Autonomous Region, China[J]. Chinese Journal of Applied Ecology, 2023, 34(5): 1305-1312.
[6]	范艺然, 刘焕, 闫征南, 等. 春秋分日保温被顶卷对南北向大棚内光照影响的模拟[J]. 中国农业气象, 2021, 42(8): 676-685.
	Fan Y R, Liu H, Yan Z N, et al. Simulation of influences of thermal insulation quilt top roll on the light environment in the north-south greenhouse on equinox day[J]. Chinese Journal of Agrometeorology, 2021, 42(8): 676-685.
[7]	程陈, 黎贞发, 董朝阳, 等. 日光温室黄瓜和芹菜不同位置消光系数模拟及验证[J]. 农业工程学报, 2020, 36(21): 243-252.
	Cheng C, Li Z F, Dong C Y, et al. Simulation and validation of extinction coefficient at different positions of cucumber and celery in solar greenhouse[J]. Transactions of the Chinese Society of Agricultural Engineering, 2020, 36(21): 243-252.
[8]	Cossu M, Murgia L, Ledda L, et al. Solar radiation distribution inside a greenhouse with south-oriented photovoltaic roofs and effects on crop productivity[J]. Applied Energy, 2014, 133: 89-100.
[9]	毛尔晔, 张潇丹, 颉建明, 等. 日光温室主动蓄放热系统热过程模拟与参数优化研究[J]. 浙江农业学报, 2024, 36(3): 671-680.
	Mao E Y, Zhang X D, Xie J M, et al. Simulation of thermal processes and optimization of parameters for active heat storage and discharge system in solar greenhouse[J]. Acta Agriculturae Zhejiangensis, 2024, 36(3): 671-680.
[10]	许卫猛, 徐妍, 陈国立. 基于多种分析方法的糯玉米品质综合评价[J]. 浙江农业学报, 2025, 37(9): 1840-1848.
	Xu W M, Xu Y, Chen G L. Comprehensive evaluation of waxy corn quality based on various analytical methods[J]. Acta Agriculturae Zhejiangensis, 2025, 37(9): 1840-1848.
[11]	赵云霞, 施文艺, 胡慧, 等. 日光温室鲜食番茄品种的筛选与多元化统计分析评价[J]. 江苏农业科学, 2025, 53(7): 180-190.
	Zhao Y X, Shi W Y, Hu H, et al. Screening, diversified statistical analysis and evaluation of fresh tomato cultivars in solar greenhouse[J]. Jiangsu Agricultural Sciences, 2025, 53(7): 180-190.
[12]	孟鑫, 吕剑, 罗石磊, 等. 不同营养液浓度对日光温室番茄果实品质的影响[J]. 中国蔬菜, 2021(10): 85-90.
	Meng X, Lyu J, Luo S L, et al. Effects of different nutrient solution concentrations on tomato fruit quality in solar greenhouse[J]. China Vegetables, 2021(10): 85-90.
[13]	吕欢欢, 牛源艺, 张漫, 等. 日光温室光照强度与空气温湿度变化趋势分析[J]. 农业机械学报, 2021, 52(S1): 410-417.
	Lyu H H, Niu Y Y, Zhang M, et al. Analysis of variation trend of light intensity and air temperature and humidity in solar greenhouse[J]. Transactions of the Chinese Society for Agricultural Machinery, 2021, 52(S1): 410-417.
[14]	李苇, 李惠玲, 王岩. 华南地区两种典型温室环境因子时空分布比较[J]. 北方园艺, 2021(21): 49-54.
	Li W, Li H L, Wang Y. Comparative on space-time distribution of environmental factors of two types of greenhouse in South China[J]. Northern Horticulture, 2021(21): 49-54.
[15]	曲佳, 须晖, 王蕊, 等. 日光温室番茄群体太阳总辐射量的分布规律及其与光合作用的关系[J]. 西北农林科技大学学报(自然科学版), 2011, 39(6): 178-184.
	Qu J, Xu H, Wang R, et al. Solar radiation distribution and relationship between solar radiation and photosynthesis of tomato canopy in solar greenhouse[J]. Journal of Northwest A&F University(Natural Science Edition), 2011, 39(6): 178-184.
[16]	孙志凌, 曹青, 张汉辰, 等. 宁夏地区雨季特征时空变化规律及其归因分析[J]. 人民长江, 2022, 53(9): 64-71.
	Sun Z L, Cao Q, Zhang H C, et al. Spatio-temporal evolution of rainy season characteristics and their causes in Ningxia Region[J]. Yangtze River, 2022, 53(9): 64-71.
[17]	张晨阳. 不同产地的椰糠对几种蔬菜出苗率的影响[J]. 现代园艺, 2023, 46(24): 1-2.
	Zhang C Y. Effects of coco peat from different origins on the seedling emergence rate of several vegetables[J]. Contemporary Horticulture, 2023, 46(24): 1-2.
[18]	吕赢, 迟翔丹, 王越, 等. 不同配比蚯蚓粪基质对黄瓜幼苗的影响[J]. 北方园艺, 2025(5): 48-55.
	Lyu Y, Chi X D, Wang Y, et al. Effects of different ratios of vermicompost substrates on cucumber seedlings[J]. Northern Horticulture, 2025(5): 48-55.
[19]	叶选, 张继红, 陈心韵, 等. 基于模糊隶属函数算法评估水生植物净化污水能力[J]. 江西科学, 2023, 41(3): 449-454.
	Ye X, Zhang J H, Chen X Y, et al. The fuzzy membership function algorithm was applied to evaluate the ability of aquatic plants to purify sewage[J]. Jiangxi Science, 2023, 41(3): 449-454.
[20]	万清, 杨小渔, 吴丹, 等. 沙棘果渣还田对水稻土性质、温室气体排放和微生物数量的影响[J]. 浙江大学学报(农业与生命科学版), 2022, 48(4): 483-492.
	Wan Q, Yang X Y, Wu D, et al. Effects of returning seabuckthorn fruit residue into field on paddy soil properties, greenhouse gas emissions and microbial numbers[J]. Journal of Zhejiang University(Agriculture and Life Sciences), 2022, 48(4): 483-492.
[21]	Spaninks K, Lamers G, van Lieshout J, et al. Light quality regulates apical and primary radial growth of Arabidopsis thaliana and Solanum lycopersicum[J]. Scientia Horticulturae, 2023, 317: 112082.
[22]	张芳, 王佩欣, 何勇, 等. 基于物联网的阳台微型温室作物生长环境因子探究[J]. 浙江农业学报, 2020, 32(2): 234-242.
	Zhang F, Wang P X, He Y, et al. Study on crop growth environment factors in mini-greenhouse in balcony based on Internet of Things[J]. Acta Agriculturae Zhejiangensis, 2020, 32(2): 234-242.
[23]	刘琦, 塔娜, 焦巍, 等. 日光温室作物冠层温湿度时空分布及预测模型[J]. 北方园艺, 2019(17): 56-65.
	Liu Q, Ta N, Jiao W, et al. Spatial temporal distribution and prediction model of canopy temperature and humidity in greenhouse[J]. Northern Horticulture, 2019(17): 56-65.
[24]	王璐, 朱进, 彭玉全, 等. 春季晴天塑料大棚内不同位置小气候变化分析[J]. 长江大学学报(自科版), 2018, 15(2): 19-21.
	Wang L, Zhu J, Peng Y Q, et al. Analysis of climate change of sunny day in the plastic shed during spring[J]. Journal of Yangtze University(Natural Science Edition), 2018, 15(2): 19-21.
[25]	范方华, 王璐, 朱进, 等. 春季阴天塑料大棚内不同位置环境变化规律[J]. 长江大学学报(自科版), 2018, 15(6): 7-9.
	Fan F H, Wang L, Zhu J, et al. Variation of environment in different positions of plastic shed in overcast days in spring[J]. Journal of Yangtze University(Natural Science Edition), 2018, 15(6): 7-9.
[26]	乐章燕, 石茗化, 魏渠成, 等. 大长度日光温室东西方向的温度变化特征[J]. 贵州农业科学, 2022, 50(8): 94-102.
	Le Z Y, Shi M H, Wei Q C, et al. Temperature variation characteristics in east-west direction of solar greenhouse with large length[J]. Guizhou Agricultural Sciences, 2022, 50(8): 94-102.
[27]	赵建贵, 李志伟, 王文俊, 等. 日光温室番茄种植环境参数时空分布测试与分析[J]. 山西农业科学, 2019, 47(12): 2172-2176.
	Zhao J G, Li Z W, Wang W J, et al. Spatial and temporal distribution test and analysis of tomato planting environment parameters in solar greenhouse[J]. Journal of Shanxi Agricultural Sciences, 2019, 47(12): 2172-2176.
[28]	于明英, 肖娟, 邱照宁, 等. 不同天气条件对沙培日光温室小气候的影响[J]. 北方园艺, 2017(9): 42-45.
	Yu M Y, Xiao J, Qiu Z N, et al. Effect of different weather conditions on microclimate of sand cultured solar greenhouse[J]. Northern Horticulture, 2017(9): 42-45.
[29]	庞敏晖, 左强, 邹国元, 等. 日光温室不同种植位置温光变化及对结球生菜产量的影响[J]. 中国农学通报, 2020, 36(34): 38-43.
	Pang M H, Zuo Q, Zou G Y, et al. The variation of temperature and light at different planting locations in solar greenhouse and its effect on lettuce yield[J]. Chinese Agricultural Science Bulletin, 2020, 36(34): 38-43.
[30]	孙世宇, 范海燕, 刘洪禄, 等. 基于主成分分析的温室白萝卜水氮耦合效应[J]. 江苏农业科学, 2024, 52(5): 159-165.
	Sun S Y, Fan H Y, Liu H L, et al. Water-nitrogen coupling effect of greenhouse white radish based on principal component analysis[J]. Jiangsu Agricultural Sciences, 2024, 52(5): 159-165.
[31]	张红丽, 南伟, 张卫华, 等. 黄沙在温室黄瓜育苗中的基质化利用效果[J]. 蔬菜, 2025(8): 46-56.
	Zhang H L, Nan W, Zhang W H, et al. Substrate utilization effect of yellow sand on cucumber seedling raising in greenhouse[J]. Vegetables, 2025(8): 46-56.

传感器类别 Sensor category	传感器类型 Sensor type	量程 Range	精度 Precision	生产商 Producer
气温 Temperature	SM1210B-12	-30~85 ℃	±0.5 ℃	徐州法拉电子科技有限责任公司 Xuzhou Fara Electronic Technology Co., Ltd.
空气湿度 Air humidity	SM1210B-12	0~100%	±3%	徐州法拉电子科技有限责任公司 Xuzhou Fara Electronic Technology Co., Ltd.
光照度 Light illuminance	SM1210B-12	0~2 600 μmol·${{\mathrm{m}}^{-}}^{2}$·s^-1	±156 μmol·${{\mathrm{m}}^{-}}^{2}$·s^-1	徐州法拉电子科技有限责任公司 Xuzhou Fara Electronic Technology Co., Ltd.
基质温度 Substrate temperature	JHT-UP	-40~60 ℃	±0.5 ℃	成都佳锂科技有限公司 Chengdu JAALEE Technology Co.,Ltd.

传感器类别 Sensor category	传感器类型 Sensor type	量程 Range	精度 Precision	生产商 Producer
气温 Temperature	SM1210B-12	-30~85 ℃	±0.5 ℃	徐州法拉电子科技有限责任公司 Xuzhou Fara Electronic Technology Co., Ltd.
空气湿度 Air humidity	SM1210B-12	0~100%	±3%	徐州法拉电子科技有限责任公司 Xuzhou Fara Electronic Technology Co., Ltd.
光照度 Light illuminance	SM1210B-12	0~2 600 μmol·${{\mathrm{m}}^{-}}^{2}$·s^-1	±156 μmol·${{\mathrm{m}}^{-}}^{2}$·s^-1	徐州法拉电子科技有限责任公司 Xuzhou Fara Electronic Technology Co., Ltd.
基质温度 Substrate temperature	JHT-UP	-40~60 ℃	±0.5 ℃	成都佳锂科技有限公司 Chengdu JAALEE Technology Co.,Ltd.

测点 Point	气温/℃ Temperature/℃			空气湿度/% Air humidity/%			光照度/(μmol·m^-2·s^-1) Light illuminance/(μmol·m^-2· s^-1)			基质温度/℃ Substrate temperature/℃
测点 Point	最大值 Maximum	最小值 Minimum	平均值 Average	最大值 Maximum	最小值 Minimum	平均值 Average	最大值 Maximum	最小值 Minimum	平均值 Average	最大值 Maximum	最小值 Minimum	平均值 Average
1	23.11	11.19	16.64	94.05	75.20	84.28	356.69	24.78	215.55	22.00	11.28	16.74
2	26.21	14.20	19.68	99.90	82.00	92.66	305.97	26.85	167.12	22.16	11.45	16.92
3	25.17	12.49	18.23	97.84	79.60	88.42	264.57	17.33	135.59	21.80	11.08	16.59
4	24.22	11.57	17.69	93.69	74.00	82.64	334.49	19.01	193.94	21.65	10.98	16.43
5	23.53	11.56	17.05	96.84	76.40	86.16	195.42	11.33	115.68	23.80	11.75	17.24

测点 Point	气温/℃ Temperature/℃			空气湿度/% Air humidity/%			光照度/(μmol·m^-2·s^-1) Light illuminance/(μmol·m^-2· s^-1)			基质温度/℃ Substrate temperature/℃
测点 Point	最大值 Maximum	最小值 Minimum	平均值 Average	最大值 Maximum	最小值 Minimum	平均值 Average	最大值 Maximum	最小值 Minimum	平均值 Average	最大值 Maximum	最小值 Minimum	平均值 Average
1	23.11	11.19	16.64	94.05	75.20	84.28	356.69	24.78	215.55	22.00	11.28	16.74
2	26.21	14.20	19.68	99.90	82.00	92.66	305.97	26.85	167.12	22.16	11.45	16.92
3	25.17	12.49	18.23	97.84	79.60	88.42	264.57	17.33	135.59	21.80	11.08	16.59
4	24.22	11.57	17.69	93.69	74.00	82.64	334.49	19.01	193.94	21.65	10.98	16.43
5	23.53	11.56	17.05	96.84	76.40	86.16	195.42	11.33	115.68	23.80	11.75	17.24

处理 Treatment	株高/mm Plant height/mm	茎粗/mm Stem thickness/mm	叶面积/mm² Leaf area/mm²	叶片数 Number of leaves	SPAD
a组Group a	79.00±9.61 c	3.00±0.01 b	2 914.23±182.25 c	5.00±0 a	44.83±4.84 a
b组Group b	80.00±5.29 c	3.07±0.01 b	3 036.15±243.36 b	5.00±0 a	43.20±3.24 a
c组Group c	95.00±6.25 a	3.37±0.04 a	4 520.95±1 056.25 a	5.00±0 a	38.03±2.25 b
d组Group d	66.67±4.00 d	2.67±0.01 c	2 605.49±139.24 d	4.00±0 a	45.68±5.77 a
e组Group e	89.50±6.76 b	3.20±0.02 ab	3 067.48±445.21 b	5.00±0 a	41.86±2.89 ab

Effect of spatial heterogeneity of solar greenhouse environment on the growth performance of tomato seedlings

RichHTML

PDF (PC)

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 9

References 31

Related Articles 7

Recommended Articles

Metrics

Comments

指标 Index	主成分1 Principal component 1	主成分2 Principal component 2
株高Plant height	0.408 809	-0.185 408
茎粗Stem thickness	0.405 605	0.100 055
叶面积Leaf area	0.394 653	-0.026 533
SPAD	-0.417 120	0.162 079
全株鲜重Fresh weight of whole plant	0.414 580	0.136 257
全株干重Dry weight of whole plant	0.344 449	0.366 792
壮苗指数Seedling index	0.675 714	0.003 071
根冠比Root and shoot ratio	-0.219 290	0.564 665
特征值Eigenvalue	5 587 000	2 185 000
方差贡献率/%Variance contribution rate/%	69.843	27.312
累计贡献率/%Cumulative variance contribution rate/%	69.843	97.155
权重Weight	0.718 882	0.281 118

处理 Treatment	μ(X₁)	μ(X₂)	综合得分 Comprehensive score	排序 Rank
a组Group a	0.462 359	0.975 993	0.607	3
b组Group b	0.383 882	0.081 507	0.299	4
c组Group c	1	0.07 974	0.741	2
d组Group d	0	0	0	5
e组Group e	0.784 438	1	0.845	1
