Promoter cloning and expression analysis of the ARF-GEF gene NtGNL2a from Nicotiana tabacum

doi:10.3969/j.issn.1004-1524.20240850

Acta Agriculturae Zhejiangensis ›› 2025, Vol. 37 ›› Issue (10): 2032-2041.DOI: 10.3969/j.issn.1004-1524.20240850

• Crop Science • Previous Articles Next Articles

Promoter cloning and expression analysis of the ARF-GEF gene NtGNL2a from Nicotiana tabacum

JIN Xin¹^,²(), LIN Rui², LIU Yan², XU Jiasheng²^,³, CHEN Qionglin², YUAN Lu², XUE Dawei¹, ZHENG Peng²^,^*(), XU Shengchun²^,⁴

1. College of Life and Environmental Sciences, Hangzhou Normal University, Hangzhou 311121, China
2. Xianghu Laboratory, Hangzhou 311231, China
3. College of Agriculture, Yangtze University, Jingzhou 434025, Hubei, China
4. Institute of Digital Agriculture, Zhejiang Academy of Agricultural Sciences, Hangzhou 310021, China

Received:2024-10-08 Online:2025-10-25 Published:2025-11-13

Abstract

Abstract:

The ADP-ribosylation factor guanine nucleotide exchange factor (ARF-GEF) gene family plays a crucial role in regulating vesicle transport and cytoskeletal dynamics in plant cells, which is essential for polarized cell growth. In this study, using the tobacco variety Zhongyan 100 (Nicotiana tabacum cv. Zhongyan 100), we identified a total of 10 ARF-GBF subfamily members in the tobacco genome through bioinformatics methods. Phylogenetic analysis revealed that NtGNL2a is a homolog of the Arabidopsis AtGNL2. The tissue expression pattern analysis showed that NtGNL2a is specifically expressed in tobacco flower, with the highest expression in pollen and trace expression in other tissues. A recombinant plant expression vector, pCambia1301-NtGNL2apro::GUS, was constructed and transformed into the wild-type Zhongyan 100. GUS histochemical staining results indicated that the NtGNL2a promoter drives GUS gene expression specifically in the pollen of transgenic tobacco. This study provides a basis for subsequent functional studies of the NtGNL2a gene and offers a new regulatory element for driving the specific expression of target genes in pollen through genetic engineering techniques.

Key words: Nicotiana tabacum, NtGNL2a, pollen specific expression, GUS histochemical staining

CLC Number:

S572

JIN Xin, LIN Rui, LIU Yan, XU Jiasheng, CHEN Qionglin, YUAN Lu, XUE Dawei, ZHENG Peng, XU Shengchun. Promoter cloning and expression analysis of the ARF-GEF gene NtGNL2a from Nicotiana tabacum[J]. Acta Agriculturae Zhejiangensis, 2025, 37(10): 2032-2041.

Figures/Tables 8

References 22

[1]	GILLINGHAM A K, MUNRO S. The small G proteins of the ARF family and their regulators[J]. Annual Review of Cell and Developmental Biology, 2007, 23: 579-611.
[2]	刘士平, 王璐, 薛艳红, 等. ARF-GEF基因家族的研究进展[J]. 遗传, 2009, 31(10): 982-992.
	LIU S P, WANG L, XUE Y H, et al. Research progress in ARF-GEF gene family[J]. Hereditas, 2009, 31(10): 982-992. (in Chinese with English abstract)
[3]	SZTUL E, CHEN P W, CASANOVA J E, et al. ARF GTPases and their GEFs and GAPs: concepts and challenges[J]. Molecular Biology of the Cell, 2019, 30(11): 1249-1271.
[4]	QUILTY D, GRAY F, SUMMERFELDT N, et al. Arf activation at the Golgi is modulated by feed-forward stimulation of the exchange factor GBF1[J]. Journal of Cell Science, 2013: jcs.130591.
[5]	QUILTY D, CHAN C J, YURKIW K, et al. The Arf-GDP-regulated recruitment of GBF1 to Golgi membranes requires domains HDS1 and HDS2 and a Golgi-localized protein receptor[J]. Journal of Cell Science, 2018, 132(4): jcs208199.
[6]	JIA D J, CAO X, WANG W, et al. GNOM-LIKE 2, encoding an adenosine diphosphate-ribosylation factor-guanine nucleotide exchange factor protein homologous to GNOM and GNL1, is essential for pollen germination in Arabidopsis[J]. Journal of Integrative Plant Biology, 2009, 51(8): 762-773.
[7]	RICHTER S, GELDNER N, SCHRADER J, et al. Functional diversification of closely related ARF-GEFs in protein secretion and recycling[J]. Nature, 2007, 448(7152): 488-492.
[8]	MAYER U, B TTNER G, J RGENS G. Apical-basal pattern formation in the Arabidopsis embryo: studies on the role of the gnom gene[J]. Development, 1993, 117(1): 149-162.
[9]	WANG L, LIAO F L, ZHU L, et al. NtGNL1 is involved in embryonic cell division patterning, root elongation, and pollen tube growth in tobacco[J]. The New Phytologist, 2008, 179(1): 81-93.
[10]	LIAO F L, WANG L, YANG L B, et al. NtGNL1 plays an essential role in pollen tube tip growth and orientation likely via regulation of post-Golgi trafficking[J]. PLoS One, 2010, 5(10): e13401.
[11]	李玲, 尤海涛, 王腾毅, 等. NtGNL1基因通过调控囊泡运输影响烟草根毛的极性生长[J]. 植物科学学报, 2016, 34(4): 593-601.
	LI L, YOU H T, WANG T Y, et al. NtGNL1 influences root hair growth by regulating vesicle trafficking in tobacco[J]. Plant Science Journal, 2016, 34(4): 593-601. (in Chinese with English abstract)
[12]	CHEN C J, WU Y, LI J W, et al. TBtools-Ⅱ: a “one for all, all for one” bioinformatics platform for biological big-data mining[J]. Molecular Plant, 2023, 16(11): 1733-1742.
[13]	LIVAK K J, SCHMITTGEN T D. Analysis of relative gene expression data using real-time quantitative PCR and the 2 (-delta delta C(T)) method[J]. Methods, 2001, 25(4): 402-408.
[14]	JEFFERSON R A, KAVANAGH T A, BEVAN M W. GUS fusions: beta-glucuronidase as a sensitive and versatile gene fusion marker in higher plants[J]. The EMBO Journal, 1987, 6(13): 3901-3907.
[15]	辛可行, 廖芳蕾, 陈文荣, 等. NtGNL2基因克隆及蛋白结构分析[J]. 山西农业科学, 2015, 43(9): 1093-1097, 1101.
	XIN K X, LIAO F L, CHEN W R, et al. Gene clone and protein structure analysis of NtGNL2[J]. Journal of Shanxi Agricultural Sciences, 2015, 43(9): 1093-1097, 1101. (in Chinese with English abstract)
[16]	FRANZUSOFF A, SCHEKMAN R. Functional compartments of the yeast Golgi apparatus are defined by the sec7 mutation[J]. The EMBO Journal, 1989, 8(9): 2695-2702.
[17]	MCFARLANE H E, WATANABE Y, YANG W L, et al. Golgi- and trans-Golgi network-mediated vesicle trafficking is required for wax secretion from epidermal cells[J]. Plant Physiology, 2014, 164(3): 1250-1260.
[18]	RODRIGUEZ-FURLAN C, EMAMI A, VAN NORMAN J M. Distinct ADP-ribosylation factor-GTP exchange factors govern the opposite polarity of 2 receptor kinases[J]. Plant Physiology, 2024, 194(2): 673-683.
[19]	GELDNER N, ANDERS N, WOLTERS H, et al. The Arabidopsis GNOM ARF-GEF mediates endosomal recycling, auxin transport, and auxin-dependent plant growth[J]. Cell, 2003, 112(2): 219-230.
[20]	MORIWAKI T, MIYAZAWA Y, FUJII N, et al. GNOM regulates root hydrotropism and phototropism independently of PIN-mediated auxin transport[J]. Plant Science, 2014, 215: 141-149.
[21]	CASANOVA J E. Regulation of ARF activation: the Sec7 family of guanine nucleotide exchange factors[J]. Traffic, 2007, 8(11): 1476-1485.
[22]	BROOKS E G, ELORRIAGA E, LIU Y, et al. Plant promoters and terminators for high-precision bioengineering[J]. Biodesign Research, 2023, 5: 0013.

引物名称 Primer name	序列(5'→3') Primer sequence (5'→3')	功能 Function
NtGNL2a-CDS-F	GGTTTTGATGTCTTGAGATGATTAATG	序列验证Sequence verification
NtGNL2a-CDS-R	CTGTTCATCACAACACTCTAATCA	序列验证Sequence verification
NtGNL2a-RTF	GTTTTGCTCTTGGTGAGGATT	表达量检测Expression level detection
NtGNL2a-RTR	CTTCTTCAACAGCATAGGGATAG	表达量检测Expression level detection
NtEF1a-RTF	CTGCAACAAGATGGATGCTAC	表达量检测Expression level detection
NtEF1a-RTR	ACCAACAGGGACAGTACCAAT	表达量检测Expression level detection
NtGNL2apro-EASY-F	CAATTTGTCTAATATTGTTCAAT	启动子克隆Promoter cloning
NtGNL2apro-EASY-R	TAATCATCTCAAGACATCAAA	启动子克隆Promoter cloning
NtGNL2apro-F	acgacggccagtgcc aagcttCAATTTGTCTAATATTGTTCAATGTCCT	植物表达载体构建 Construction of plant expression vector
NtGNL2apro-R	aaatttaccctcagatcta ccatggTAATCATCTCAAGACATCAAAACCATCC	植物表达载体构建 Construction of plant expression vector
GUS-test-F	AAGGGATCTTCACTCGCGAC	阳性鉴定Positive identification
M13R-48	AGCGGATAACAATTTCACACAGGA	阳性鉴定Positive identification

引物名称 Primer name	序列(5'→3') Primer sequence (5'→3')	功能 Function
NtGNL2a-CDS-F	GGTTTTGATGTCTTGAGATGATTAATG	序列验证Sequence verification
NtGNL2a-CDS-R	CTGTTCATCACAACACTCTAATCA	序列验证Sequence verification
NtGNL2a-RTF	GTTTTGCTCTTGGTGAGGATT	表达量检测Expression level detection
NtGNL2a-RTR	CTTCTTCAACAGCATAGGGATAG	表达量检测Expression level detection
NtEF1a-RTF	CTGCAACAAGATGGATGCTAC	表达量检测Expression level detection
NtEF1a-RTR	ACCAACAGGGACAGTACCAAT	表达量检测Expression level detection
NtGNL2apro-EASY-F	CAATTTGTCTAATATTGTTCAAT	启动子克隆Promoter cloning
NtGNL2apro-EASY-R	TAATCATCTCAAGACATCAAA	启动子克隆Promoter cloning
NtGNL2apro-F	acgacggccagtgcc aagcttCAATTTGTCTAATATTGTTCAATGTCCT	植物表达载体构建 Construction of plant expression vector
NtGNL2apro-R	aaatttaccctcagatcta ccatggTAATCATCTCAAGACATCAAAACCATCC	植物表达载体构建 Construction of plant expression vector
GUS-test-F	AAGGGATCTTCACTCGCGAC	阳性鉴定Positive identification
M13R-48	AGCGGATAACAATTTCACACAGGA	阳性鉴定Positive identification

分类 Classification	名称 Name	功能 Function	数量 Quantity
光响应 Light response	Box 4	参与光响应的保守DNA模块的一部分 Part of a conserved DNA module involved in light responsiveness	4
	G-box	参与光反应的顺式作用调控元件cis-acting regulatory element involved in light responsiveness	3
	GT1-motif	光响应元件Light responsive element	2
	TCT-motif	光响应元件的一部分Part of a light responsive element	1
激素响应 Hormone response	ABRE	参与脱落酸响应的顺式作用元件cis-acting element involved in the abscisic acid responsiveness	1
	CGTCA-motif	参与茉莉酸甲酯(MeJA)响应的顺式作用调控元件 cis-acting regulatory element involved in the MeJA-responsiveness	2
	TCA-element	参与水杨酸响应的顺式作用元件cis-acting element involved in salicylic acid responsiveness	1
胁迫响应 Stress response	LTR	参与低温响应的顺式作用元件cis-acting element involved in low-temperature responsiveness	1
	ARE	对厌氧诱导至关重要的顺式作用调控元件 cis-acting regulatory element essential for the anaerobic induction	1
	TC-rich repeats	参与防御和应激反应的顺式作用元件 cis-acting element involved in defense and stress responsiveness	1
生长发育 Growth and development	O2-site	参与玉米醇溶蛋白代谢调控的顺式作用调控元件 cis-acting regulatory element involved in zein metabolism regulation	1

分类 Classification	名称 Name	功能 Function	数量 Quantity
光响应 Light response	Box 4	参与光响应的保守DNA模块的一部分 Part of a conserved DNA module involved in light responsiveness	4
	G-box	参与光反应的顺式作用调控元件cis-acting regulatory element involved in light responsiveness	3
	GT1-motif	光响应元件Light responsive element	2
	TCT-motif	光响应元件的一部分Part of a light responsive element	1
激素响应 Hormone response	ABRE	参与脱落酸响应的顺式作用元件cis-acting element involved in the abscisic acid responsiveness	1
	CGTCA-motif	参与茉莉酸甲酯(MeJA)响应的顺式作用调控元件 cis-acting regulatory element involved in the MeJA-responsiveness	2
	TCA-element	参与水杨酸响应的顺式作用元件cis-acting element involved in salicylic acid responsiveness	1
胁迫响应 Stress response	LTR	参与低温响应的顺式作用元件cis-acting element involved in low-temperature responsiveness	1
	ARE	对厌氧诱导至关重要的顺式作用调控元件 cis-acting regulatory element essential for the anaerobic induction	1
	TC-rich repeats	参与防御和应激反应的顺式作用元件 cis-acting element involved in defense and stress responsiveness	1
生长发育 Growth and development	O2-site	参与玉米醇溶蛋白代谢调控的顺式作用调控元件 cis-acting regulatory element involved in zein metabolism regulation	1
